e-Dose Dosing Pump

Price upon request
Brand Initiative Engg
Minimum Order Quantity: 1000
Accept Small Orders No
Country Of Origin: India
Check

Sign In to see your saved Addresses

Check availability of product in your area

Write a Review

Model e Dose Neo-10 LPH


Option of Auto pH Correction System available

Backlit LCD Display User friendly knob linked with digital display for adjusting dosing frequency with facility of password lock

Dosing head conveniently located next to front controls for easy maintenance access

Built-in ARV with separate discharge point to prevent chemical spill on hands Double ball NRV

Diaphragm made of solid PTFE to ensure maximum life Batch and Interval dosing features E-dose NEO with 4 to 20mA

E-dose NEO can be supplied with the provision to receive 4 to 20mA input


Application:

Can receive signal from flow transmitter, pH transmitter, Conductivity transmitter etc. And can be programmed to dose proportional to the received signal. E-dose NEO Pulse i/p

In this version, the pump can receive signals directly from a sensor and dosing rate can be adjusted for proportional dosing


Application:

A flow sensor can be connected to provide flow proportional dosing. E-dose NEO can then be programmed on site to multiply or divide the received pulses by any factor to trigger dosing. E-dose NEO Pulse Relay o/p E-dose can be supplied with the provision of relay output


Application:

When there is a fault with the pump, the relay will get triggered to indicate visually or with a buzzer.

When Level in Dosing Tank goes below set Level, the relay will get triggered to indicate visually or with a buzzer. Ensuring that your system is always dosing chemical.

The EnviroTech E-Dose Dosing Pump is a state-of-the-art solution engineered for precise chemical dosing in water treatment, industrial processes, and various other applications. Designed for accuracy and reliability, this pump ensures optimal chemical injection, enhancing process efficiency and safety.

  • Additional Information

    Key Features and Benefits:

    High Precision Dosing: Offers dosing rates of 1.5, 3.0, 6.0, and 10.0 liters per hour at 4 kg/cm², ensuring accurate chemical delivery.
    User-Friendly Interface: Equipped with a 16x2 dual-line LCD display for clear and easy monitoring of dosing parameters.
    Robust Construction: Built with durable materials to withstand demanding industrial environments, ensuring longevity and consistent performance.
    Energy Efficient: Operates at a power consumption of 30 watts at 400 strokes per minute, promoting energy savings.
    Flexible Integration: Compatible with 4/6 mm suction and discharge tubing, facilitating easy installation and integration into existing systems
    Technical Specifications:
    Dosing Rates: 1.5, 3.0, 6.0, and 10.0 liters per hour at 4 kg/cm².
    Frequency: Up to 400 strokes per minute.
    Electrical Requirements: 230 V AC, 50 Hz.
    Power Consumption: 30 watts at 400 strokes per minute.
    Tubing Size: 4/6 mm suction and discharge tubing.
    Display: 16x2 dual-line LCD.
    Unique Selling Points (USPs):
    Integrated pH Control: Features an inbuilt pH transmitter, making it ideal for acid and alkali dosing applications.
    Splash-Proof Enclosure: Designed with a splash-proof enclosure to protect internal components, ensuring durability and reliability
    Advanced Diaphragm Technology: Utilizes a PTFE diaphragm for longer life and enhanced chemical compatibility.
    Call to Action:
    Enhance your chemical dosing operations with the EnviroTech E-Dose Dosing Pump. Its precision, durability, and user-friendly features make it the ideal choice for industries requiring accurate chemical injection. Contact us today to learn more and place your order.
